Manual electrode switching breakout box for leap-frog soil imaging belts

Manual electrode switching breakout box for leap-frog soil imaging belts

  • Price: Price on application

The Lund receiver has no internal switchbox. We ran 8 channel streamers directly into it without problem but for terrestrial survey a manual switchbox was necessary. We constructed this as shown with numerous 9-pin d-sub connectors for connection of each pair of sets of 8 electrodes at a time so that there were 16 electrodes connected for differential use. Individual 4mm sockets for the 16 electrodes also are supplied.



Enquire about this product
